Alsense Tire Wired tire temperature sensor with PU case and DTM06-4S connector rear axle kit (RL+RR)

To measure tire temperature for racing, drag racing and tuning on the road

Technology from Motorsport with CAN Bus based tire temperature measurement

Finally available and only at TurboZentrum, the Alsense Tire Wired tire temperature sensor. The Alsense Tire Wired is an advanced multi-channel infrared tire temperature sensor with CAN connectivity. Fully configurable, 16 temperature channels / tire with a refresh rate of up to 64Hz. Comes either with an unterminated loom or DTM06-4S connector. Consistent temperature monitoring even when in harsh conditions due to newer sensor technology.

Ideally suited for our CANchecked displays with the CBD08 Can Bus (CC22100) extension module. This makes it easy to measure the temperature at the tires. Especially in motorsports and on the 1/4 mile, the correct tire temperature is a key to racing success. Thanks to the monitoring, suspension settings can be improved and the optimum temperature window for the maximum hysteresis (phase angle between applied force and movement) can be determined.

Delivery content

– Rear axle kit (RL+RR) Alsense Tire Wired Temperature sensors with PU case and DTM06-4S connector
– Documentation

Powerful

• 16 temperature channels / tire
• Up to 64Hz refresh rate

Consistent readings

• New sensor and case design mean stable and consistent readings even with transient ambient temperatures

Easy Install

• All units come pre-programmed for the desired position and specifications. Just wire in & play
• Customizable terminating connector to suit any motorsport loom
• Supply voltage range 5-20V (no additional components required)

Compatibilty

• Fully compatible with any CAN race dash or logger
• Plug&Play looms available

Flexible

• Choose either a state-of-the-art polyamide-based case with excellent density and strength or a more traditional CNC aluminum

Support

• Product-specific documents and files

Capabilities

• Temperature Channels: 16/8/4/1
• Sample Rate: Up to 64Hz
• Accuracy: 1* C
• Temperature Range: -40 to 300° C

Physical

• Dimensions: 48 x 25 x 12mm
• Weight: 25g
• Operating temperature: -40 to 85* C
• Protection Rating: IP66

Electrical:

• Supply Voltage: 5 – 20V
• Supply current: 15mA

CAN

• CAN: 2.0A (11-bit identifier)
• Configurable baud rate: 500kbps / 1 Mbps
• Resolution: 0.1* C
• CAN ID: Depending on position on car

Wiring

• 0.5m AWG22 cable DR25
• [Optional] DTM06-4S plug
• Please get in touch for other connector options and full-loom manufacturing
