10BAR FLUID PRESSURE SENSOR 2022 VERSION
£100.00
To use this element install or activate XStore Core plugin
High Quality Fluid pressure sensor which work in Oil or Fuels
Technical Specification
| Process Connection | 1/8 Inch NPT Male |
| Safe Over Range | 150% of Range |
| Burst Pressure | >300% of Range |
| Accuracy | 0.5%FS |
| Thermal Effects | Zero +0.04% FS/C |
| Output | 0.5v to 4.5v |
| Supply | 5V |
| Operating Temp Range | |
| Construction | Stainless Steel |
| Electrical Connection | 60cm – 26AWG Screened Cable |
| Protection Class | IP67 |
| Weight | 60g |
| Installation Manual | http://www.syvecs.com/downloads/Syvecs_10Bar_pressure_2022.pdf |
|---|
